Ariel Work Platform Working Height 29m For Indoor Or Outdoor

Basic Information
Place of Origin: China
Brand Name: JESH
Certification: CE/ISO
Model Number: TB27J
Minimum Order Quantity: 1 unit
Price: US$80000-US$140000
Packaging Details: packed as per internaitonal export standard.
Delivery Time: 10-30days
Payment Terms: T/T, L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability: 1000 units per year
Contact Now
Feature: Telescopic Boom Lift Lift Drive/Actuation: Hydraulic
Platform Height: 27m Platfrom Capacity: 360kg
Power: Diesel Engine Weight: 14500kg
Application: Factory Building, Shipping Building Etc. Color: Light Green Gray / As Per Your Demand
Power Source: Diesel Engine
High Light:

telescopic manlift


telescopic platform lift

 Ariel Work Platform Working Height 29m For Indoor Or Outdoor


JESH Telescopic boom lift/ manlift


JESH telescopic boom lift covers working height from 27m-43m, which is suitable for indoor or outdoor use on rough ground.

It is featured with advanced working height and outreach ability beyond the industry, which allow you to locate the working point accurately.

With outstanding gradeability and rough terrain performance, the working efficiency is greatly improved.


We are capable to manufacture the whole machine by ourself with advanced concept of production. With imported and self-developed manufacturing equipment, the quality of each process is strictly controlled, which fully guarantees the production quality of product.


Technical Parameters

Model TB27J
Dimentions Metric
Max Working Height 29.0m
Max Platform Height 27.0m
Max Horizontal Outreach 21.1m
Extendable depth downward 1.6m
Platform Width 0.91m
Platform Length 2.44m
Height-Stowed 3.01m
Length-Stowed 14.4m
Transportation 11.9m
Width 2.48m
Wheelbase 3.0m
Ground Clearance-Center 0.39m
Load capacity(unrestricted) 230kg
Load capacity(restricted) 360kg
Tail swing 1.574m
Min. Turning Radius(inside/outside) 3.7m/6.6m
Turntable Swing 360°continuous
Platform Rotation 160°
Jib rotation -60°~75°
Drive Speed(stowed) 5.4km/h
Drive Speed(extended) 1.1km/h
Control DC12V Proportional
Drive type 4 Wheels
Max. Grade ability 45%
Tire-solid foam filled( Dia.×Width) 1033×450mm
Engine Kohler KDI 2504 TCR(55.4kW)
Fuel Diesel
Hydraulic Oil Tank Capacity 150L
Fuel Tank Capacity 120L
