| Place of Origin: | China |
|---|---|
| Brand Name: | JESH |
| Certification: | CE |
| Model Number: | SS0812EM |
| Minimum Order Quantity: | 1Unit |
| Price: | Negotiation |
| Packaging Details: | Regular factory packing |
| Delivery Time: | 45 days |
| Payment Terms: | T/T, L/C, D/P, D/A |
| Supply Ability: | 4000 Units per month |
| Color: | Green | Working Height: | 10.1m |
|---|---|---|---|
| Platform Height: | 8.12m | Max Drive Speed: | 3.5km/h |
| Capacity On Extension: | 120kg | Gradeability: | 25% |
| Turning Radius(inside/outside): | 0/2.1m | Tire: | 40.5*12.7m |
| Material: | High Impact Steel Structure | Battery: | 24V/260Ah |
| High Light: | single man electric lift,scissor lift platform |
||
Long warranty 8m electric man lift 450KG scissor aerial work platform for maintenance
Characters:
1,Sweden imported High corrosion steel scissor arm.
2,easy maintenance.
3,Forklift hole on the side for loading and discharging.
4,Unique pothole protection design.
5,Orbital plane,easy for cleaning.
6,Unique design of symmetrical steering mechanism with equal turning angle and speed for left and right, allowing stable turning.
Specification sheet:
| Model | Electric man lift SS0812EM |
| Dimentions | Metric |
| Max.Working Height | 10.1m |
| Max.Platform Lifting Height | 8.1m |
| Platform Length | 2.27m |
| Platform Length-Extended | 3.17m |
| Platform Extension | 0.9m |
| Platform Width | 1.14m |
| Height -Unfolded | 2.35m |
| Height-folded | 1.82m |
| Wheelbase | 1.87m |
| Min. Ground Clearance-stowed | 10cm |
| Min. Ground Clearance-Raised | 2cm |
| Productivity | |
| Platform capacity | 450kg |
| Extension platform capacity | 120kg |
| Gradeability | 25% |
| Tire | 40.5x12.7cm |
| Power | Electric |
| Engine | Bettery 24V/260Ah |
| Hydraulic Oil Tank Capacity | 25L |
| Machine Total Weight | 2550kg |
Product Description
Jesh Standard packing,with hard plastic bag to cover the whole machine and with steel wire holds the machine foot.
Shipping by sea with around 40-45 days arrrive your destination port.
