| Place of Origin: | China |
|---|---|
| Brand Name: | JESH |
| Certification: | CE |
| Model Number: | SS1312HL |
| Minimum Order Quantity: | 1Unit |
| Price: | Negotiation |
| Packaging Details: | Regular factory packing |
| Delivery Time: | 45 days |
| Payment Terms: | T/T, L/C, D/P, D/A |
| Supply Ability: | 4000 Units per month |
| Color: | Green | Working Height: | 13.8m |
|---|---|---|---|
| Platform Height: | 11.8m | Width: | 1.14m |
| Length: | 2.48m | Capacity: | 320KG |
| Engine: | Deutz | After-sales Service Provided: | Service Machinery Overseas |
| Product Name: | Aerial Work Platform | ||
| High Light: | Aerial Self Propelled Scissor Lift,14m Self Propelled Scissor Lift,Hydraulic Self Propelled Scissor Lift |
||
Mobile hydraulic Self propelled 14m scissor lift aerial working platform
Chassis
Performance
Main Specs
Technical Parameters
| Model | SS1312HL |
| Dimentions | Metric |
| Working Height | 14.8m |
| Platform Height | 12.8m |
| Platform Length | 2.36m |
| Platform Length-Extended | 3.26m |
| Platform Extension | 0.9m |
| Platform Width | 1.10m |
| Height -Unfolded | 2.61m |
| Height-folded | 2.08m |
| Wheelbase | 1.93m |
| Min. Ground Clearance-stowed | 10cm |
| Min. Ground Clearance-Raised | 2cm |
| Productivity | |
| Platform capacity | 320kg |
| Extension platform capacity | 120kg |
| Drive Speed | 3.5km/h |
| Gradeability | 25% |
| Raise/Lower Speed | 59/45sec |
| Turning Radius(Inside/outside) | 0/2.17m |
| Tire | 40.5x12.7cm |
| Power | Electric Hydraulic |
| Engine | Optional( Pekins,Kohler,Deutz,Commins,Yanmar) |
| Hydraulic Oil Tank Capacity | 25L |
| Machine Total Weight | 3061kg |
| Bettery |
24V/225Ah |
