| Place of Origin: | China |
|---|---|
| Brand Name: | JESH |
| Certification: | CE/ISO |
| Model Number: | SS1312HL |
| Minimum Order Quantity: | 1 unit |
| Price: | US$10000-US$18000 |
| Packaging Details: | MEWPs 10m hydraulic scissor lift for factory building will be packed as per internaitonal export standard. |
| Delivery Time: | 45days |
| Payment Terms: | T/T, L/C, D/A, D/P |
| Supply Ability: | 1000 units per month |
| Feature: | Self-propelled | Platfrom Capacity: | 320kg |
|---|---|---|---|
| Power: | Battery | Lift Drive/Actuation: | Hydraulic |
| Weight: | 2925kg | Application: | Factory Building, Shipping Building, Airport, Seaport Etc. |
| Color: | Light Green Gray / As Per Your Demand | Material: | High Impact Steel Structure |
| Max.Working Height: | 14.8m | Max.Platform Lifting Height: | 12.8m |
| High Light: | hydrualic pover sky lift,sky cissor lift |
||
ght 15m 42 feet Self propelled work elevated lift platform for building
Data sheet :
| Item name | SS1312HL 14m self propelled elevated lift platform |
| Size | Metric |
| Max.Working Height | 14.8m |
| Max.Lifting Height | 12.8m |
| Height-Stowed( restricted) | 2.62m |
| Height-Stowed(Unrestricted) | 2.08m |
| Length-Stowed | 2.56m |
| Width-Stowed | 1.2m |
| Platform Size( L×W×H) | 2.4m x 1.1m x 1.3m |
| Platform Length-extended | 3.29m |
| Platform Width | 0.9m |
| Wheelbase | 1.97m |
| Ground Clearance | 12cm/2cm |
| Performance | |
| Platform Capacity | 320kg |
| Extension Platform Capacity | 120kg |
| Platform Occupancy(indoor/outdoor) | 2/0 |
| Max Wind Speed | 0m/s |
| Drive speed-stowed | 3.5km/h |
| Drive speed-Raised | 0.8km/h |
| Gradeability-Stowed | 25% |
| Turning radius-inside | 0 |
| Turining radius-outside | 2.17m |
| Raise/lower speed | 59s/45s |
| Drive Mode | double front wheel |
| Multi-Plate Brake | double rear wheel |
| Non-marking tire(Dia.×W) | 405mmx127mm |
| Max Tilt Angle | 1.5°/3° |
| Power | |
| Battery | 24V/260Ah, 4 x 6V Batteries |
| Hydraulic oil tank capacity | 25L |
| Weight | 3061kg |
Mainly specification:
Characteristic:
Factory show and customer visit
