| Place of Origin: | CHINA |
|---|---|
| Brand Name: | JESH |
| Certification: | CE/ISO |
| Model Number: | SS0607HM |
| Minimum Order Quantity: | 1 |
| Price: | 1 Unit |
| Packaging Details: | Regular factory packing |
| Delivery Time: | 45days |
| Payment Terms: | L/C, D/A, D/P, , T/T |
| Supply Ability: | 4000 Units per month |
| Working Height: | 7.9m | Platform Height: | 5.9m |
|---|---|---|---|
| Width: | 0.76m | Length: | 1.84m |
| Wheelbase: | 1.32m | Battery: | 24V/225Ah |
| Weight: | 1500kg | Material: | High Impact Steel Structure |
| Overall Dimensions: | 1.84x0.76x2.18m | Table Size: | 1.66x0.75x1.24m |
| Battery Voltage: | 24V/225Ah | Engine: | Koher |
| High Light: | mobile scissor lift,mobile hydraulic scissor lift |
||
Hydraulic Mobile Lift plaform with Max.Working height 19ft for indoor
FEATURES:
1) Unique design of bidirectional retracting scissor arm providing better stability and comfort of machine.
2) Unique pothole protection design with higher reliability.
3) Super low maintenance self-lubricating bearings in some components
4) Platform can be dismantled for transportation
5) Orbital plane easy for cleaning.
6m elevated work platform is widely used in indoor workshop building site, hotel, apartment house, and so on.
Mainly used to installing, repairing and cleaning at height.
Technical Parameters:
| Dimension | L 1.84m*W 0.76m*H 2.18m |
| Model | SS0607HM |
| working height | 7.9m |
| Platform Height | 5.9m |
| Machine Width | 0.74m |
| Machine height(Railing unfolded) | 2.18m |
| Machine height(Railing folded) | 1.8m |
| Platform size | 1.63*0.74m |
| Platform Extension Length | 0.9m |
| Ground Clearance(stowed) | 0.07m |
| Wheelbase | 1.32m |
| Model | SS0607HM |
| Platform Capacity | 230kg |
| Platform Capacity-Extension | 100kg |
| Maximum Workers Number | 2 |
| Turning Radius(inside/outside) | 0/1.5m |
| Dirive Speed(Platform Lowered) | 4km/h |
| Drive Speed (Plateform Elevated) | 0.8km/h |
| Lift/Lower Time | 16/26 sec |
| Gradeability | 25% |
| Maximun Working Slope | 3° |
| Tire Size | 32.3*10m |
| Batteries | 24V/225Ah |
Jesh Standard packing,with hard plastic bag to cover the whole machine and with steel wire holds the machine foot.
Shipping by sea with around 40-45 days arrrive your destination port.
We provide long term warranty: 5 years for the main structural,2 years for the whole machine.
If we have a dealer in your local so we can make the after-sell service.If don't have,please contact us for the technical supports,we can full support you online
Hunan JESH Heavy Industry Co.,Ltd has strong R&D ability , in-depth researching on aerial working equipment, and there are innovation in mechanical structure, hydraulic system, electrical control, and a number of invention patents, appearance patents and utility model patents. All of the products have been gone through stability and limited working condition calculation; and fatigue test has been carried out on each model to ensure the reliability and safety of the products.
