Diesel Articulating Boom Lift Maximum Platform Height 14.7m
Product Features
1. Diesel articulating boom lifts compact structure design equipped with complete safety devices large crossing height precise control.
2. They are designed to meet the needs of different industries and applications.
3. They provide a versatile solution for building maintenance, tree trimming, window cleaning, or construction work at heights.
4. With their robust construction and powerful capabilities, these lifts are essential equipment for many professionals in the field.
Model | AB14J |
Size | Metric |
Maximum Working Height | 16.7m |
Maximum Platform Height | 14.7m |
Maximum Horizontal Outreach | 8.1m |
Maximum Up & Over Clearance | 8.25m |
Platform Size | 1.83X0.76m |
B)Length-Stowed | 6.72m |
Width-Stowed | 2.28m |
A)Height-Stowed | 2.47m |
Wheelbase | 2.5m |
Ground Clearance | 0.4m |
Performance | |
Maximum Lifting Capacity | 230Kg |
Maximum Platform Occupancy | 2ppls |
Platform Rotation | ±90° |
Vertical Jib Rotation | 135° |
Turntable Rotation | 355° |
Turntable Tail Swing | 0m |
Drive Speed-Stowed | 5Km/h |
Drive Speed-Raised | 0.8Km/h |
Gradeability | 45% |
Maximum Working Slope | 5° |
Turning Radius (inside) | 1.87m |
Turning Radius (outside) | 4.8m |
Drive & Steer Mode | 4X4X2 |
Tire Size | 33X12-20 |
Power | |
Power Supply | 36Kw@2200rpm~2600rpm |
Fuel Tank Capacity | 100L |
Hydraulic Oil Tank Capacity | 110L |
Control Voltage | 12V |
Weight | |
Machine Weight | 8070Kg |
Standard Compliance | |
EN280 GB25849 |
※ The picture and technical information may vary by the update policy, the changes will be without prior notice.
The Aerial Work Platform Production Line
1. Full Capacity for Production Processing: Professional Manufacturing Equipments to ensure customers one-stop cooperation
2. High Quality & Efficiency: High consistency of processing quality, to ensure efficiency and high precision machining characteristics
3. It plays a crucial role in providing safe and efficient equipment for various industries, such as construction, maintenance, and utilities. The production line's commitment to quality and innovation ensures that customers receive reliable and high-performing aerial work platforms for their specific needs.
