18M Working Height Diesel Articulating Boom Lift 4WD Hydraulic

18M Working Height Diesel Articulating Boom Lift 4WD Hydraulic

  • High Light

    18M Diesel Articulating Boom Lift

    ,

    Diesel Articulating Boom Lift 4WD

    ,

    4WD Boom Lift

  • Drive Model
    4WD
  • Platform Rotation
    ±90°
  • Place of Origin
    CHINA
  • Brand Name
    KINGDA
  • Certification
    CE
  • Model Number
    AB16J
  • Minimum Order Quantity
    1 UNIT
  • Price
    (TBD)USD
  • Packaging Details
    Export packing
  • Delivery Time
    60 Days
  • Payment Terms
    T/T
  • Supply Ability
    NO LIMITED

18M Working Height Diesel Articulating Boom Lift 4WD Hydraulic



Diesel Articulating Boom Lift Working Height,18m Control Voltage 12V





Product Features



1. Diesel articulating boom lifts are a type of heavy-duty equipment used in construction, maintenance, and various industries.

2. They are designed to provide vertical and horizontal reach to access elevated areas.

3. These lifts feature an articulated boom that can be extended and manoeuvred to reach difficult-to-access locations.
4. One of the key advantages of diesel articulating boom lifts is their ability to reach higher heights.

5. They are equipped with powerful diesel engines that provide the necessary power to lift heavy loads and operate in rugged terrains.



18M Working Height Diesel Articulating Boom Lift 4WD Hydraulic 0

Model AB16J
Size Metric
Maximum Working Height 18m
Maximum Platform Height 16m
Maximum Horizontal Outreach 9.55m
Maximum Up & Over Clearance 8.25m
Platform Size 1.83X0.76m
B)Length-Stowed 7.26m
Width-Stowed 2.28m
A)Height-Stowed 2.4m
Wheelbase 2.5m
Ground Clearance 0.4m
Performance
Maximum Lifting Capacity 230Kg
Maximum Platform Occupancy 2ppls
Platform Rotation ±90°
Vertical Jib Rotation 135°
Turntable Rotation 355°
Turntable Tail Swing 0.09m
Drive Speed-Stowed 5Km/h
Drive Speed-Raised 0.8Km/h
Gradeability 45%
Maximum Working Slope
Turning Radius (inside) 1.87m
Turning Radius (outside) 4.8m
Drive & Steer Mode 4X4X2
Tire Size 33X12-20
Power
Power Supply 36Kw@2200rpm~2600rpm
Fuel Tank Capacity 100L
Hydraulic Oil Tank Capacity 110L
Control Voltage 12V
Weight
Machine Weight 8700Kg
Standard Compliance
EN280 GB25849



※ The picture and technical information may vary by the update policy, the changes will be without prior notice.







The Aerial Work Platform Production Line



1. Full Capacity for Production Processing: Professional Manufacturing Equipments to ensure customers one-stop cooperation
2. High Quality & Efficiency: High consistency of processing quality, to ensure efficiency and high precision machining characteristics

3. It plays a crucial role in providing safe and efficient equipment for various industries, such as construction, maintenance, and utilities. The production line's commitment to quality and innovation ensures that customers receive reliable and high-performing aerial work platforms for their specific needs.
