Staff Lift Diesel Telescopic Aerial Work Platform 20m

Staff Lift Diesel Telescopic Aerial Work Platform 20m

Products - Diesel Telescopic Boom Lift
  • High Light

    telescopic aerial work platform

    ,

    telescopic aerial platform

    ,

    telescopic platform

  • Gradeability
    45%
  • Load Capacity
    340kg
  • Place of Origin
    CHINA
  • Brand Name
    KINGDA
  • Certification
    CE
  • Model Number
    TB18J
  • Minimum Order Quantity
    1 UNIT
  • Price
    （TBD）USD
  • Packaging Details
    Export packing
  • Delivery Time
    60 Days
  • Payment Terms
    T/T
  • Supply Ability
    NO LIMITED

Staff Lift Diesel Telescopic Aerial Work Platform 20m

  • Staff Lift Diesel Telescopic Aerial Work Platform 20m
  • Staff Lift Diesel Telescopic Aerial Work Platform 20m
  • Staff Lift Diesel Telescopic Aerial Work Platform 20m
  • Staff Lift Diesel Telescopic Aerial Work Platform 20m
  • Staff Lift Diesel Telescopic Aerial Work Platform 20m
Get Price Contact Now



Diesel Telescopic Boom Lift 20m Working Height





Product Features



1. The telescopic boom lift's quick setup and deployment save valuable time on job sites, improving overall project efficiency.

2. Its telescopic boom design offers a combination of height and horizontal reach, providing access to distant or elevated work areas.

3. The boom lift's tilting platform feature allows operators to work at various angles, increasing flexibility in completing different tasks.
4. Its high weight capacity enables the boom lift to accommodate multiple operators and equipment simultaneously for efficient workflow.

Staff Lift Diesel Telescopic Aerial Work Platform 20m 0



Model TB18J
Size Metric
Maximum Working Height 20m
Maximum Platform Height 18m
Maximum Horizontal Outreach 15m
Platform Size 2.44X0.91m
Length-Stowed 9.07m
Width-Stowed 2.42m
Height-Stowed 2.58m
Wheelbase 3m
Ground Clearance(Center) 0.37m
Performance
Maximum Lifting Capacity 480Kg
Maximum Platform Occupancy 2 pls
Platform Rotation ±90°
Vertical Jib Rotation 135°
Turntable Rotation 355°
Drive Speed-Stowed 5km/h
Drive Speed-Raised 1.1Km/h
Gradeability 45°
Maximum Working Slope 5°
Turning Radius (inside) 2.76m
Turning Radius (outside) 6.09m
Drive &Steer Mode 4X4X2
Tyre Size 33X12-20
Power
Power Supply 36Kw@2400rpm~2600rpm
Fuel Tank Capacity 151L
Hydraulic Oil Tank Capacity 160L
Control Voltage 12V
Weight
Machine Weight 9500Kg
Standard Compliance EN280 GB25849





※ The picture and technical information may vary by the update policy, the changes will be without prior notice.
